Designing Tactile Cyber-Physical Systems (TCPS)

• Designed and executed a Tactile Cyber-Physical System (TCPS) connecting a haptic device and a robotic arm for live teleoperation.
• Developed pose correction algorithm that automatically adjusts the pose of a robot while gripping a tool.
• Developed tremor suppression algorithm that suppresses tremors in the robot arm while controlling it using a haptic device.
• Detailed project page 🔗

Time Sensitive Networking (TSN) switch

• µTAS - Designed a P4-MicroC-based SmartNIC that offloaded Time-Aware Shaper and achieved 20µs latency between hosts across two switches.
• Implemented packet de-duplication algorithms that ensured 100% and 99.83% packet delivery for two and tweleve streams respectively across two links each with 10% loss.
• EdgeP4 - Embedding intelligence for pose correction and tremor suppression in P4-programmable edge switches, reducing control loop latency (<100µs) and network load (99% reduction) and demonstrating versatility in algorithm-switching for distinct tasks via P4's match-actions.
• Detailed project page 🔗

Yaw control of a CubeSat using reaction wheels

• Designed a suspended CubeSat body and achieved precise control of its yaw using reaction wheels using a manually tuned PID controller.
• Modeled it in Simulink and implemented Model Reference Adaptive Control (MRAC) using the MIT rule and achieved better performance compared to PID control.
• Detailed project page 🔗

FPV Goggles

• Designed a first person view goggles which is lightweight and affordable.
• Application: live streaming and recording the doctor's view during a surgery for training.
• Detailed project page 🔗

Acoustics Based Localization

• Developed an application to locate multiple wireless edge devices with embedded microphones by using audio signals from speakers.
• Simulated a few localization algorithms using MATLAB. Implemented KNN fingerprinting based localization of the receivers and achieved an accuracy of 98%.
• Novelty - Unlike the usual source localization, here, the receivers (mics) are localized when the locations of speakers are known.
• Detailed project page 🔗

Airplane IoT data analytics and management

• Developed machine learning algorithms to classify anomalies and take corrective actions using real-time data generated from sensors from a MATLAB/Simulink model of an aircraft environmental control system.
• Novelty - Developed an algorithm that does linear interpolation between non-consecutive data points from time series data to adaptively store data based on a cost function which balances storage space savings and error in reconstruction of data. Achieved 96% savings in storage space.
• Detailed project page 🔗

5G - AMMAZING

• An end to end 5G mmWave system for infotainment.
• Novelty - Data & control plane of a video stream split over 5G and regular Wi-Fi.
• 🥇 Won first place and a cash award of $7,200 in 5G Hackathon 2020 by the Government of India with 1100+ participating teams.

Wi-Fi Modelling

• Modelling & simulation of IEEE 802.11n & 802.11ac using MATLAB.
• Performance Metrics: throughput, packet error rate & range.
• Implementing Rate Control Algorithms in MATLAB.
• Detailed project page 🔗

Video casting

• As 2.4 & 5 GHz Wi-Fi is congested in an aircraft cabin in which 400+ passengers cast media onto seat back displays in close proximity, using IEEE 802.11ad, 60GHz Wi-Fi (Wi-Gig) & 802.11ax (Wi-Fi 6E) was explored.
• MATLAB WLAN Toolbox was used to simulate the physical behavior of Wi-Fi transmissions in a dense environment.
• Novelty - Developed an algorithm that dynamically allocates different channels to 400 transmitters such that the packet error ratio is zero (PER = 0).
• Detailed project page 🔗

Designing 3D printed products

Building and flying RC planes
